Level II Specs + Features
Charger Specifications
AC Power Output: Up to 9.6kW (A0 A) requiring a 50A breaker, or 11.5kW (48 A) requiring a 60 A breaker
Power Supply Voltage: Single phase, 208 V or 240 V AC, 60Hz.
Rated Current Settings (A): 12, 16, 24, 32,40, 48.
Wire Size: 8 AWG or 6 AWG (90 °C rated wire).
Network Type: Split phase.
Energy Metering: NTEP-certified, 1% accuracy.
Over Voltage Protection: 267 V (maximum 275V).
Ground Fault Protection: 20mA.
Environmental
Usability + Design
Features
Connect With
Us Today
Ready to electrify your future with Quantum Unity? Contact us to explore how our cutting-edge charging solutions can benefit you. Fill out the form below to get started. Whether you're looking to install new charging stations or interested in learning more about our technology, our team is here to provide all the information and support you need. Join us in driving towards a sustainable future, one charge at a time.
